Headset Microphone
|
Input Type: Dynamic
Input Impedance: >= 1K
Mic Limiter Threshold: 0dBu ± 3dB
Mic Limiter Range: >= 15dB
|
Program Line Input
|
Maximum Level before Clipping: >= 20dBu
Input Impedance: >= 5K
|
Program Mic Input
|
Maximum Level before Clipping: >= -35dB
Input Impedance: >= 1K
|
Headset Output
|
Load Impedance: >= 8
Output Impedance: <= 25
Output Limiter Threshold: +5dBu ± 3dB
Maximum Output Level before Distortion: >= 17dBu
|
Partyline Output
|
O Noise: < -74dBu
Output Impedance: >10K
|
Partyline Input
|
Crosstalk: <-60dB
Max level before Clipping: >= 12dBu
Sidetone Null Capability: > 25dB
|
Stage Announce/Balanced Line Out
|
Type: Balanced Output Impedance: >= 200
Load Impedance: >= 600
|
Frequency Response
|
Headset Mic – Partyline: 200 – 18KHz ± 3dB
Headset Mic – Line Out: 200 – 18KHz ± 3dB
Program Input – Partyline: 200 – 20KHz ± 3dB
Program Input – Headset Out: 200 – 18KHz ± 3dB
Partyline – Headset Out: 200 – 18KHz ± 3dB
|
Max Distortion
|
Headset Mic – Partyline: <= 0.5%
Headset Mic – Line Out: <= 0.5%
Program Input – Partyline: <= 0.2%
Program Input – Headset Out: <= 0.2%
Partyline – Headset Out: <= 0.2%
|
Noise
|
Headset Mic – Partyline: < -70dBu
Program Input – Partyline: < -85dBu
Program Mic – Partyline: < -70dBu
Program Input – Headset Out: < -60dBu
Program Mic – Headset Out: < -40dBu
Partyline – Headset Out: < -50dBu
|
Max Gain
|
Headset Mic – Partyline: 41dB ± 2dB
Headset Mic – Announce Out: 55dB ± 3dB
Program Input – Partyline: >= -16dB
Program Mic – Partyline: 41dB ± 2dB
Program Input – Headset Out: >= 18dB
Program Mic – Headset Out: >= 70dB
Partyline – Headset Out: >= 34dB
|
Mains Power
|
Input Voltage Range: 100 – 240V AC
Input Frequency Range: 50 – 60Hz
Input Power: <= 60V AC
Output Voltage: 30VDC ± 0.5V
Output Current per Channel (Continuous): 1.2A
|
Output Current per Channel
|
(Peak): 2 A (Do not exceed the 1.2A rating for more than 2 seconds per 1 minute period)
Short Circuit Recovery Time (1st short):<= 0.5 sec
Short Circuit Recovery Time >= 20 shorts in 20sec):<= 20 sec
|
Environmental
|
32 – 122°F (0 – 50°C)
|
Dimensions
|
3 x 8.5 x 10in (HxWxD)
(76 x 216 x 254mm)
|
Weight
|
5.0lbs (2.3kg)
|
